| Inner | NR+BR |
| Reinforcement layer | High tensile textile cord with helix steel wire |
| Cover | NR+BR |
| Working temperature | -35℃~80℃ |
| Colour | Black |
| Application | It is used for pumping, rivers and lakes, transporting harbor rivers, other dredging projects. |
| I.D. | W.P. | B.P. | Length | ||||
| mm | inch | psi | bar | psi | bar | ft | m |
| 51 | 2” | 150 | 10 | 450 | 30 | 200 | 61 |
| 64 | 2-1/2” | 150 | 10 | 450 | 30 | 200 | 61 |
| 76 | 3” | 150 | 10 | 450 | 30 | 200 | 61 |
| 89 | 3-1/2” | 150 | 10 | 450 | 30 | 200 | 61 |
| 102 | 4” | 150 | 10 | 450 | 30 | 200 | 61 |
| 152 | 6” | 150 | 10 | 450 | 30 | 132 | 40 |
| Note: Specifications, pressures, colors, etc, can be customized according to requirements | |||||||
